Contactor MC-12B-440 12A /AC3 Bob. 440V LS 50/60HZ // 4004878 Marca:ls
SKU 4004878 · Unidad base: unit
MC-12a AC440V 50/60Hz SCREW 1a (Metasol) EXP (MC12A-30-10-R7-S-E) Características técnicas: Product code: 1317001300; Product type: Metasol Contactor; Main contact: 3NO; Auxiliary contact: 1NO; Control voltage: AC440V 50/60Hz; Type of terminal: Screw; Local/Export: Export; Standards: IEC 60947-4-1, IEC 60947-5-1, UL508; Certificates: KR, LR, BV, DNV, ABS, NK, RINA; Number of poles: 3P; Rated operational voltage [Ue]: 690V; Rated insulation voltage [Ui]: 690V; Rated withstand voltage [Uimp]: 6kV; Rated frequency [Hz]: 50/60Hz; Maximum operating rate in operating cycles per hour(AC3): 50/60Hz; Mechanical durability (mil. operations): 50/60Hz; Electrical durability (mil. operations): 50/60Hz; Rated operational current (AC-1): 25A.
Ingresa o regístrate para consultar el stock registrado.
Ingresar ↗La solicitud no reserva mercadería ni confirma un pedido.
Consultar ficha técnica ↗Características del producto
- Product code
- 1317001300
- Product type
- Metasol Contactor
- Main contact
- 3NO
- Auxiliary contact
- 1NO
- Control voltage
- AC440V 50/60Hz
- Type of terminal
- Screw
- Local/Export
- Export
- Standards
- IEC 60947-4-1, IEC 60947-5-1, UL508
- Certificates
- KR, LR, BV, DNV, ABS, NK, RINA
- Number of poles
- 3P
- Rated operational voltage [Ue]
- 690V
- Rated insulation voltage [Ui]
- 690V
- Rated withstand voltage [Uimp]
- 6kV
- Rated frequency [Hz]
- 50/60Hz
- Maximum operating rate in operating cycles per hour(AC3)
- 50/60Hz
- Mechanical durability (mil. operations)
- 50/60Hz
- Electrical durability (mil. operations)
- 50/60Hz
- Rated operational current (AC-1)
- 25A
- Power (AC-1)
- -
- Current (AC-1)
- -
- Motor power (AC-3)
- -
- Motor power (AC-4)
- 4kW at 380/440V
- Rated operational current (AC-3)
- -
- Rated operational current (AC-4)
- 9A at 380/440V
- Rated operational current (DC-3,5)
- -
- Rated operational current (DC-1)
- -
- Type 2 Coordination
- -
- Motor power (UL/CSA)
- 10hp at 550~600V for 3 phase motors
- NEMA size
- 10hp at 550~600V for 3 phase motors
- Rated Short-time withstand current
- 28A at =15min
- Conductor size (AWG)
- 16~8
- Conductor size (mm2)
- 1.5~10
- The max. number of conductor
- 1.5~10
- Conductor type
- Solid, Stranded
- Conductor charateristic
- 65/75? Cu-wire only
- Main terminal size
- M3.5
- Crimp terminal (mm)
- M3.5
- Torque (lb-in)
- M3.5
- Torque (Nm)
- M3.5
- Torque (kgf.cm)
- M3.5
- Degree of protection
- IP20
- Ambient air temperature
- -5? ~ +55? at operation (AC type)
- Operating altitude
- 3000m(8900ft)
- Shock resistance (1/2 sin wave=11ms)
- 10G at closed
- Vibration resistance (Conforming to IEC68-2-6) (5~300Hz)
- 4G at closed
- Flame resistance
- 960? at conforming to IEC695-2-1
- REACH
- Yes
- RoHS
- Yes
- WEEE
- Yes
- Weight
- 0.3kg
- Size width
- 45mm / 1.77inch
- Size height
- 73.5mm / 2.89inch
- Size depth
- 80.4mm / 3.17inch
- Drawings
- MC-6a~18a AC.png
- Control voltage limit [Uc]
- 85~110%
- Consumption at 20℃
- 9VA at holding
- Heat dissipation
- 2.3W at holding
- Operating time
- 4~19ms at opening
- Applicable Accessories
- Metasol MS_31.png
