Contactor MC 3P 75A / 220VAC-60HZ ,AC3 // 4005585 Marca LS

SKU 4005585 · Unidad base: unit

MC-75a AC200V 50Hz 220V 60Hz LUG 1a1b (Metasol) EXP (MC75A-30-11-LM7-L-E) Características técnicas: Product code: 1382008800; Product type: Metasol Contactor; Main contact: 3NO; Auxiliary contact: 1NO 1NC; Control voltage: AC200V 50Hz 220V; Type of terminal: Lug; Local/Export: Export; Standards: IEC 60947-4-1, IEC 60947-5-1, UL508; Certificates: KR, LR, BV, DNV, ABS, NK, RINA; Number of poles: 3P; Rated operational voltage [Ue]: 1000V; Rated insulation voltage [Ui]: 1000V; Rated withstand voltage [Uimp]: 8kV; Rated frequency [Hz]: 60Hz; Maximum operating rate in operating cycles per hour(AC3): 1200; Mechanical durability (mil. operations): 12; Electrical durability (mil. operations): 2; Rated operational current (AC-1): 125A.

La solicitud no reserva mercadería ni confirma un pedido.
