Interruptor Termomagnetico Riel BKN 2X20A, 6KA/415V LS

SKU 4101304 · Unidad base: unit

BKN 2P B20 NEW ROGY Características técnicas: Product Code: 06120270R0; Product type: Miniature Circuit Breaker; [In] Rated current: 20A at 30? conforming to EN/IEC 60898-1 IEC60947-2; [Ue] rated operational voltage: 400V; Poles description: 2P; Number of protected poles: 2; Network type: AC (50/60 Hz); Type of trip: Thermal-magnetic; Neutral position: -; Earth-leakage sensitivity: -; Residual current off-time: -; Earth-leakage protection time delay: -; Earth-leakage protection class: -; Max. operating voltage Ub max.: 440 V AC; Min. operating voltage Ub min.: 24 V AC - 24 V DC; [Uimp] rated impulse withstand voltage: 4 kV; [Ui] rated insulation voltage: 500 V; Residual current tripping technology: -.

La solicitud no reserva mercadería ni confirma un pedido.
