Interruptor Termomagnetica Riel BKH 3X125A , 15KA/415V // 4101505 Marca: LS

SKU 4101505 · Unidad base: unit

BKH 3P C125A NEW ROGY Características técnicas: Product Code: 06110348R0; Product type: Molded case circuit breaker; [In] Rated current: 125A at 30℃ conforming to EN/IEC 60947-2; [Ue] rated operational voltage: 400V; Poles description: 3P; Number of protected poles: 3; Network type: AC (50/60 Hz); Type of trip: Thermal-magnetic; Neutral position: -; Earth-leakage sensitivity: -; Residual current off-time: -; Earth-leakage protection time delay: -; Earth-leakage protection class: -; Max. operating voltage Ub max.: 440 V AC; Min. operating voltage Ub min.: 24 V AC - 24 V DC; [Uimp] rated impulse withstand voltage: 4 kV; [Ui] rated insulation voltage: 400 V; Residual current tripping technology: -.
